HIKVISION DS-7324HGHI-SH User Manual

User Manual of Digital Video Recorder
113
7.1 Backing up Record Files
Before you start:
Please insert the backup device(s) into the device.
7.1.1 Backing up by Normal Video Search
Purpose:
The record files can be backed up to various USB devices, such as USB flash drives, USB HDDs, and USB
writer.
Backup using USB flash drives, USB HDDs, and USB writer
Steps:
1. Enter Export interface.
Menu>Export>Normal
Figure 7. 1 Normal Export Interface
2. Set search condition and click Search button to enter the search result interface.
Figure 7. 2 Result of Normal Video Search for Backup
3. Select record files you want to back up.
Click button to play the record file if you want to check it.
Check the checkbox before the record files you want to back up.
The size of the currently selected files is displayed in the lower-left corner of the window.

HIKVISION DS-7324HGHI-SH Specifications

General

Voltage	100 - 240 V
Product color	Black
Audio input channels	4.0 channels
Audio output channels	1.0 channels
Video compression formats	H.264
RS-485 ports	1
Video input channels	24 channels
USB 2.0 ports quantity	3
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA, eSATA
Maximum HDD capacity	6000 GB
Number of HDDs supported	4
Power consumption (typical)	55 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
Dimensions (WxDxH)	445 x 390 x 70 mm
