168
User Manual of Digital Video Recorder
10.2 Managing Network HDD
Purpose:
You can add the allocated NAS or disk of IP SAN to DVR, and use it as network HDD.
Steps:
1.
Enter the HDD Information interface.
Menu > HDD>General
Figure 10. 6 HDD Information Interface
2.
Click the
Add
button to enter the Add NetHDD interface, as shown in Figure 10. 7.
Figure 10. 7 HDD Information Interface
3.
Add the allocated NetHDD.
4.
Select the type to NAS or IP SAN.
5.
Configure the NAS or IP SAN settings.
•
Add NAS disk:
1)
Enter the NetHDD IP address in the text field.
2)
Click
Search
to search the available NAS disks.
3)
Select the NAS disk from the list shown below.
Or you can just manually enter the directory in the text field of NetHDD Directory.
4)
Click
OK
to add the configured NAS disk.
Up to 8 NAS disks can be added.
