User Manual of Digital Video Recorder
70
2.
Click the button to show the general settings of the PTZ control.
Figure 4. 7 PTZ Panel - General
3.
Select a patrol in the dropdown list and click the
Call Patrol
button to call it.
4.
You can click the
Stop Patrol
button to stop calling it.
4.2.5
Customizing Patterns
Purpose:
Patterns can be set by recording the movement of the PTZ. You can call the pattern to make the PTZ movement
according to the predefined path.
Steps:
1.
Enter the PTZ Control interface.
Menu > Camera > PTZ
Figure 4. 8 PTZ Settings
2.
Choose pattern number in the dropdown list.
3.
Click the
Start
button and click corresponding buttons in the control panel to move the PTZ camera, and
click the
Stop
button to stop it.
The movement of the PTZ is recorded as the pattern.
To Next Page
