User Manual of Digital Video Recorder
42
2.5 Adding and Connecting the IP Cameras
This section is not available for the DS-7100 series DVR.
2.5.1
Setting the Admin Password for the IP Camera
Purpose:
Before adding the camera, make sure the IP camera to be added is in active status.
Steps:
1.
Select the Add IP Camera option from the right-click menu in live view mode or click Menu> Camera>
Camera to enter the IP camera management interface.
For the IP camera detected online in the same network segment, the Security status shows whether it is
active or inactive.
Figure 2. 15 IP Camera Management Interface
2.
Click the inactive icon of the camera to enter the following interface to activate it. You can also select
multiple cameras from the list and click the One-touch Activate to activate the cameras in batch.
Figure 2. 16 Activate the Camera
To Next Page
