HIKVISION DS-7608NI-E2/8P User Manual

Network Video Recorder User Manual
141
9.6 Region Exiting Detection
Purpose:
Region exiting detection function detects people, vehicle or other objects which exit from a pre-defined virtual
region, and some certain actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.5 Region Entrance Detection for operating steps to configure the region exiting
detection.
 Up to 4 rules can be configured.
9.7 Loitering Detection
Purpose:
Loitering detection function detects people, vehicle or other objects which loiter in a pre-defined virtual region for
some certain time, and a series of actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the loitering detection.
 The Threshold [1s-10s] in the Rule Settings defines the time of the object loitering in the region. If you set
the value as 5, alarm is triggered after the object loitering in the region for 5s; and if you set the value as 0,
alarm is triggered immediately after the object entering the region.
 Up to 4 rules can be configured.
9.8 People Gathering Detection
Purpose:
People gathering detection alarm is triggered when people gather around in a pre-defined virtual region, and a
series of actions can be taken when the alarm is triggered.
 Please refer to the Chapter 9.4 Intrusion Detection for operating steps to configure the people gathering
detection.
 The Percentage in the Rule Settings defines the gathering density of the people in the region. Usually, when
the percentage is small, the alarm can be triggered when small number of people gathered in the defined
detection region.
 Up to 4 rules can be configured.
9.9 Fast Moving Detection
Purpose:
Fast moving detection alarm is triggered when people, vehicle or other objects move fast in a pre-defined virtual
region, and a series of actions can be taken when the alarm is triggered.

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
