HIKVISION DS-7608NI-E2/8P User Manual

Network Video Recorder User Manual
225
DS-7604NI-E1/4P and DS-7608NI-E2/8P
Model
DS-7604NI-E1/4P
DS-7608NI-E2/8P
Video/Audio
input
IP video input
4-ch
8-ch
Two-way audio input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming bandwidth
40 Mbps
80 Mbps
Outgoing bandwidth
80 Mbps
Remote connection
32
Video/Audio
output
Recording resolution
6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P)/60 fps (N)
Sub-stream: 50 fps (P)/60 fps (N)
HDMI/VGA output
1-ch, resolution:
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,
1024 × 768/60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live view/Playback
resolution
6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
4-ch@1080p
8-ch@720p, 5-ch@1080p
Network
management
Network protocols
TCP/IP, DHCP, PPPoE, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS,
iSCSI, UPnP™, HTTPS
Hard disk
SATA
1 SATA interface for 1 HDD
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
USB interface
1 × USB 2.0 and 1 × USB 3.0
Alarm in/out
(Optional)
4/1
PoE
Interface
4 independent 100 Mbps PoE network
interfaces
8 independent 100 Mbps PoE network
interfaces
Max. Power
50 W
120 W
Supported standard
AF and AT
General
Power supply
48 VDC
100 to 240 VAC
Consumption
(without hard disk
and PoE)
≤ 10 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF )
Working humidity
10 % to 90 %
Chassis
Standalone 1U chassis
385 mm chassis
Dimensions
(W × D × H)
315 × 240 × 48 mm
(12.4" × 9.4" × 1.9")
385 × 315× 52 mm
(15.2" × 12.4" × 2.0")
Weight
(without hard disk)
≤ 1 kg (2.2 lb)

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
