HIKVISION DS-7608NI-E2/8P User Manual

Network Video Recorder User Manual
156
11.2 Configuring Advanced Settings
11.2.1 PPPoE Settings
Purpose:
Your NVR also allows access by Point-to-Point Protocol over Ethernet (PPPoE).
Steps:
1. Enter the Network Settings interface.
Menu >Configuration> Network
2. Select the PPPoE tab to enter the PPPoE Settings interface, as shown in Figure 11. 3.
Figure 11. 3 PPPoE Settings Interface
3. Check the PPPoE checkbox to enable this feature.
4. Enter User Name and Password for PPPoE access.
The User Name and Password should be assigned by your ISP.
5. Click the Apply button to save and exit the interface.
6. After successful settings, the system asks you to reboot the device to enable the new settings, and the PPPoE
dial-up is automatically connected after reboot.
You can go to Menu >Maintenance>System Info >Network interface to view the status of PPPoE connection.
Please refer to Chapter 14.1 Viewing System Information for PPPoE status.
11.2.2 Configuring HIK Cloud P2P
Purpose:
HIK Cloud P2P provides the mobile phone application and as well the service platform page to access and manage
your connected NVR, which enables you to get a convenient remote access to the surveillance system.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the Platform Access tab to enter the HIK Cloud P2P Settings interface.
3. Check the Enable checkbox to activate this feature.
4. (Optional) If required, select the checkbox of Custom and input the Server Address. The default server
address is dev.hicloudcam.com.
5. To turn the Enable Stream Encryption on, you can select its checkbox.
6. Enter the Verification Code of the device.

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
