HIKVISION DS-7608NI-E2/8P User Manual

Network Video Recorder User Manual
224
DS-7600NI-E2/N
Model
DS-7616NI-E2/8N
DS-7632NI-E2/8N
DS-7616NI-E2/16N
DS-7632NI-E2/16N
Video/Audio
input
IP video input
16-ch
32-ch
16-ch
32-ch
Two-way audio
input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Network
Incoming
bandwidth
160 Mbps
Outgoing
bandwidth
80 Mbps
Remote
connection
128
Video/Audio
output
Recording
resolution
6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P)/60 fps (N)
Sub-stream: 50 fps (P)/60 fps (N)
HDMI/VGA
output
1-ch, resolution:
1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 ×
768/60Hz
Audio output
1-ch, RCA (Linear, 1kΩ)
Decoding
Live
view/Playback
resolution
6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability
16-ch@4CIF, 12-ch@720p, 6-ch@1080p
Network
management
Network
protocols
TCP/IP, DHCP, PPPoE, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI,
UPnP™, HTTPS
Hard disk
SATA
2 SATA interfaces for 2 HDDs
Capacity
Up to 4TB for each disk
External
interface
Network
interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
8 independent 100 Mbps built-in switch
network interfaces
16 independent 100 Mbps built-in switch
network interfaces
USB interface
1 × USB 2.0 and 1 × USB 3.0
Alarm in/out
(Optional)
4/1
General
Power supply
12 VDC
Consumption
(without hard
disk)
≤ 10 W
Working
temperature
-10 ºC to +55 ºC (14 ºF to 131 ºF )
Working
humidity
10 % to 90 %
Chassis
385 mm chassis
Dimensions
(W × D × H)
385 × 315× 52 mm
(15.2" × 12.4" × 2.0")
Weight
(without hard
disk)
≤ 1 kg (2.2 lb)

HIKVISION DS-7608NI-E2/8P Specifications

General

Display modes	Live view
Maximum frame rate	60 fps
Maximum resolution	1920 x 1080 pixels
Alarm input channels	4
Video input channels	8 channels
Alarm output channels	1
Resolution at capture speed	1920x1080@60fps
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
Power consumption (typical)	10 W
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
HDD interface	Serial ATA
Maximum storage capacity	12 TB
Number of HDDs supported	2
Total installed storage capacity	0 GB

Weight and Dimensions

Depth	290 mm
Width	445 mm
Height	45 mm
Weight	1000 g
