Network Video Recorder User Manual
69
Figure 6-7 Region Entrance Detection
4. Check Enable Region Entrance Detection.
5. Optional: Check Save VCA Picture to save the captured pictures of region entrance detection
pictures.
6. Set detection rules and detection areas.
1) Select Arming Region.
Note
Up to 4 regions are selectable.
2) Set Sensitivity.
Sensitivity
The higher the value is, the easier the detection alarm will be triggered. Its range is [0-100].
3) Click Draw Region, and draw a quadrilateral in the preview window.
7. Optional: Draw the maximum size/minimum size for targets. Only the targets in the size ranging
from maximum size to minimum size will trigger line crossing detection.
1) Click Max. Size/Min. Size.
2) Draw an area in preview window.
3) Click Stop Drawing.
8. Optional: Select Detection Target as Human or Vehicle to discard alarms which are not
triggered by human body or vehicle.
9. Set the arming schedule. Refer to Configure Arming Schedule.
10. Set linkage actions. Refer to Configure Linkage Actions.
11. Click Apply.

HIKVISION DS-7816NI-I2/16P Specifications

General

Model	DS-7816NI-I2/16P
Category	Network Video Recorder
Video Input	16 Channels
IP Video Input	16 Channels
Two-Way Audio	Yes
Decoding Format	H.265+/H.265/H.264+/H.264
Synchronous Playback	16 Channels
Operating Humidity	10% to 90%
Supported Camera Resolution	Up to 12MP
Video Output	HDMI, VGA
HDMI Output Resolution	4K (3840x2160)
VGA Output Resolution	1920x1080
Audio Output	1 Channel
Recording Resolution	Up to 8MP (3840x2160)
HDD Slots	2
Hard Disk	SATA
Network Interface	1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
USB Interface	2 x USB 2.0
Power Supply	100-240V AC, 50/60Hz
Power Consumption	< 15W (without HDD)
Operating Temperature	-10°C to 55°C
Max HDD Capacity	Up to 10 TB capacity for each HDD
