HIKVISION HWN-4108MH-8P User Manual

239.255.255.255 and it is recommended to use the IP address ranging from 239.252.0.0 to
239.255.255.255.
When adding a device to the CMS soware, the mulcast address must be the same as that of
the device.
RTSP Port
RTSP (Real Time Streaming Protocol) is a network control protocol designed for use in
entertainment and
communicaons systems to control streaming media servers. The port is 554
by default.
Output Bandwidth Limit
You can check the checkbox to enable output bandwidth limit.
Output Bandwidth
Aer enable the output bandwidth limit, input the output bandwidth.
Note
●
The output bandwidth limit is used for the remote live view and playback.
●
The default output bandwidth is the maximum limit.
Figure 6-5 Port Sengs
6.2.5 Upload Logs to the Server
You can upload system logs to the server for backup.
Network Video Recorder User Manual
47
