HIKVISION iVMS-4200 User Manual

Network Camera User Manual
96
Output, etc.
12.1 Configuring Line Crossing Detection
Purpose:
Line crossing detection function detects people, vehicle or other objects which cross a
pre-defined virtual line, and some certain actions can be taken when the alarm is
triggered.
Note: Line crossing detection function varies according to different camera models.
Steps:
1. Enter the Line Crossing Detection settings interface, Configuration > Advance
Configuration >Smart Event> Line Crossing Detection.
Figure 12-1 Line Crossing Detection
2. Check the checkbox of Enable Line Crossing Detection to enable the function.
3. Select the line from the drop-down list for detection settings.
4. Click Area Settings tab and click Draw Area button, and a virtual line is
displayed on the live video.
