Basic Settings
18
1.1
System
RM Web L2B
Release
5.3
05/2012
1.1
System
The “System“ submenu in t
he basic settings menu is structured as follows:
Device Status
System data
Device view
Reloading data
Figure 4:
"System" Submenu
Device state
This section of the us
er interface (Web-based
Interface) provides
information on the device status
and the alarm states the device has
detected.
