Basic Settings
RM Web L2B
Release
5.3
05/2012
1.6
Loading/Saving the Configuration
33
1.6
Loading/Sa
ving the
Configur
at
ion
With this dialog you can:
load a configuration,
save a configuration,
enter a URL,
restore the delivery configuration,
cancel a configuration change.
Figure 12:
Load/Save dialog
32
34
