Hirschmann RSB20 User Manual

Redundancy
RM Web L2B
Release 5.3 05/2012
6.2 Rapid Spanning Tree
99
6.2.2 Rapid Spanning Tree Port
Parameter Meaning Possible Values Default Setting
STP State Here you can turn RSTP on or off
for this port. If you turn RSTP off for
this port while RSTP is globally
enabled for the device, the device
will discard RSTP frames received
on this port.
on,
off
on
Port state Displays the port state. disabled,
forwarding,
discarding,
blocking,
learning
-
Port Priority Here you enter the first byte of the
port identificatio.
16 ≤ n·16 ≤ 240 128
Port Path Cost Enter the path costs to indicate
preference for redundant paths. If
the value is 0, the Switch
automatically calculates the path
costs according to the transmission
rate.
0 - 200.000.000 0
Admin EdgePort If the parameter is set to "true“, the
port will transition to the forwarding
state. If the port nevertheless
receives an RSTP frame, it will
transition to the blocking state and
the bridge will then determine the
new port role.
.If the parameter’s value is "false“,
the port remains in the blocked state
until the bridge has determined the
port role. Only after that will the port
transition to its final state.
true, false false
Oper-Edge-Port Is "true“ if no RSTP frames have
been received, i. e., a terminal
device that does notsend RSTP
frames is connected to this port. Is
"false“ if RSTP frames have been
received, i. e., no terminal device
but a bridge is connected.
true, false -
Table 26: Port-related RSTP settings and displays
