Hiwin S Series User Manual

4.3 STG-16 outline drawing
3-Ø9.5
B.C.DØ56
Detail A
2-M5x0.8Px5DP
3-M6x1Px6DP
B.C.DØ56
Detail B
2-M3x0.5Px3DP
6-M4x0.7Px6DP
6-M2x0.4Px4.5DP
27.6
38
Ø14.6
L
(50)
Ø14.6
43
L
(50)
Right-angle Type
22.95
12
±0.05
Stroke:0~8mm
33.5
Ø100
72.3
9
12
26
6-Ø6h7
6-Ø4.5
1.9
2
19.5
30
6
±0.05
0.5 5.75
Ø4
+0.02
0.00
x2DP
4
+0.02
-0.00
x2DP
Ø12
60°
28
±0.05
0.5 27.75
4
+0.02
-0.00
x3DP
8
30.5
16
24
8
20
20
A
4
+0.02
0.00
x3DP
Connector Cable:
Straight Type B
C11UE01-1907
19
