06-4
6.3 Electrical supply
1
The 230 V system is protected by a two-pole
13 A overload release (1). (Exceptions to this
include special installations such as ultraheat,
warm water heating, etc. In this case, an addi-
tional two-pole 16 A overload circuit breaker is
installed.)
The fuse box is located in the clothes cupboard.
Before connecting the camper to the 230 V
mains, turn off the overload circuit breaker by
pressing the rocker button down.
Now you can set up an electric connection using
the cable.
Supply via mains connection
The camper receives its electric power supply
via the 230 V CEE feeder plug on the side wall of
the vehicle.
Electricity for the camper can be obtained from
the following connections:
- 230 V mains connection 50 Hz. (1)
-
via the base vehicle if it is connected using the
13-pole plug (limited functions)
- via a built-in auxiliary battery (not included).
Everything that uses 12 V, such as lighting,
water supply, etc., is available.
