Hobby ONTOUR 2018 User Manual

96
7. Installation of electrical devices
7.5 Electrical system
Assoonasthereisamainsconnection,theelectricalsystemwill
switch from battery operation to mains operation. The electrical
supplyunitusesatransformertochangetheexternalmainsvoltage
forthe12Voltelectricaldevices.Allofthelampsinthecaravanuse
12V.Onlylargeelectricaldevicessuchasthetherme,oorheating
*
,
air conditioner
*
, etc., use 230 V.
CEE-Mains hook up socket
Assignment of fuses
Electric circuit (7,5A):
children‘sbedsidelights,wardrobelight(onlyWLU),awninglight,
wall lights, ceiling light, bedside lights
Electric circuit (15 A):
children‘sbedsidelights
Electric circuit (7,5 A):
wardrobelight,leftbedsidelight(onlyWLU),ambience2,kitchen,
shower lights
Electric circuit (7,5 A):
fan,lightsaroundthewashbasin,ambience3,ambience1
Electric circuit (7,5 A):
waterpump,Toiletush,fridgelight
Assignment of fuses
The fuses for the individual internal electric circuits are located in
thelightingcontrolmodule.Theyareassignedasfollows(fromleft
toright):
Insomemodels,theremaybeslightdeviationsin
thisassignment.
Onlyreplaceblownfusesifyouknowwhatcaused
thefusetoblowandhavexedthis.
1
2
3
4
5
USB charging socket* (model-specic)
The USB charging socket
j
 is suitable only for charging USB-
compatibledevices.
The5VUSBconnectionissuppliedwithpowerfromthe12Velectric
system.
USB connection
1
1 2 3 4 5
Battery charger
j
in the wardrobe
Battery charger
Thechargersuppliesthe batterywith electric powerwhen thereis
bus-poweredmainsoperation.
• Airingthebatterychargerinsufficientlywillcausea
reduction in the charge current.
• Thesurfaceofthechargercasingmaybecomehot
whenthedeviceisinoperation.
• Thebatterychargermayonlybeopenedbyaspecia-
list.
1
