Hobby ONTOUR 2018 User Manual

171
14. Technical Data
14.3 Weights of the vehicle and equipment
Model Unladen
weight
[kg]
Basic
equipment
[kg]
Mass in ready
to drive
condition
[kg]
Technically
permissible
total mass.
[kg]
Payload
[kg]
390 SF ONTOUR 952 62 1014 1200 186
460 DL ONTOUR 1122 62 1184 1300 116
470 UL ONTOUR 1124 62 1186 1350 164
470 KMF ONTOUR 1110 47 1157 1350 193
440 SF de Luxe Edition 1038 62 1100 1300 200
460 LU de Luxe Edition 1130 62 1192 1350 158
460 UFe de Luxe Edition 1144 62 1206 1350 144
490 KMF de Luxe Edition 1196 62 1258 1400 142
495 UL de Luxe Edition 1223 62 1285 1500 215
545 KMF de Luxe Edition 1340 72 1412 1600 188
560 KMFe de Luxe Edition 1425 87 1512 1700 188
650 KMFe de Luxe Edition 1581 87 1668 1900 232
495 UL IC Line 1270 87 1357 1800 443
545 KMF IC Line 1387 72 1459 2000 541
400 SFe de Luxe 1035 62 1097 1300 203
455 UF de Luxe 1082 62 1144 1350 206
460 LU de Luxe 1118 62 1180 1350 170
460 UFe de Luxe 1139 62 1201 1350 149
490 KMF de Luxe 1193 62 1255 1400 145
495 UL de Luxe 1218 62
1280 1500 220
495 WFB de Luxe 1229 52 1281 1500 219
540 UL de Luxe 1261 87 1348 1500 152
540 KMFe de Luxe 1290 87 1377 1600 223
515 UHK de Luxe 1373 87 1460 1600 140
515 UHL de Luxe 1368 87 1455 1600 145
545 KMF de Luxe 1338 72 1410 1600 190
560 KMFe de Luxe 1417 87 1504 1700 196
460 UFe Excellent 1157 62 1219 1350 131
460 SFf Excellent 1123 47 1170 1350 180
495 UFe Excellent 1198 62 1260 1500 240
495 UL Excellent 1233 62 1295 1500 205
495 WFB Excellent 1240 52 1292 1500 208
540 UL Excellent 1273 87 1360 1500 140
540 FU Excellent 1301 77 1378 1500 122
540 UFf Excellent 1253 87 1340 1500 160
540 WLU Excellent 1254 72 1326 1500 174
560 LU Excellent 1367 87 1454 1600 146
560 KMFe Excellent 1442 87 1529 1700 171
560 WFU Excellent 1390 77 1467 1600 133
560 CFe Excellent 1375 87 1462 1600 138
