6.3 Tables
Handle for metal elevating table
Metal elevating table base
To lower
• Pullupwardsonthehandle
j
ontheright-handside.
• Useonehandtolightlypressthetabledownandswingitdown
towardsthemiddleofthecaravan.Thetableonlylocksinto
placeinthisloweredpositionwhenthehandlesnapsbackinto
itsoriginalposition.
To turn
• Therearerollersonthetablelegs,shifted45°,whichenablethe
tabletobeturnedarounditscentrepointinanydesireddirection.
Metal elevating table base
Single-post lifting
Single-post elevating table leg
To lower
• Movethelever
j
totheotherside.
• Pressontabletoptolowerthetable.
• Movethelever
j
backtoitsoriginalposition.
1
Lever
j
to lower the table
1
Thesingle-postliftingtablelegcanbeloweredandthetabletop
canbemovedaroundontopoftheleg.
• Tounlock,pullthelockingpin
k
upandthenpullthebracket
intothedesiredposition.
• Tolock,pushthebracketbacktoitsoriginalpositionuntilit
locksintoplace.
2
Articulated TV Bracket
Whendriving,theTVbracketmustalwaysbelockedin
itsoriginalposition.
Articulated TV Bracket
Themaximaldimensionsofthetelevisionare
535x351x50mm.
