Fully adjustable window stays
6.6 Windows
Catch
Window with ratcheting stays
To open
• Turnallofthewindowlatches
k
by90°.
• Pressthewindowcatchoutwardsuntilyouhearitclick.The
windowwillautomaticallyremaininthisposition.Theangleof
openingcanbeincreasedinpredenedsteps.
To close
• Liftthewindowslightlytounhookthestay.
• Closethewindow.
• Turnallofthewindowcatches
k
totheoriginalpositionso
thattheyclaspbehindthelatchesandpullthepaneintothe
seal.

Asaddedprotectionagainstfallingout,thewindows
bythechildren'sbedscanonlybeopenedslightly.
Allofthewindowcatches
j
onthelongbottomedge
ofthewindowhavelockbuttons.Toopenthesewindow
catches
j
,pressthelockbuttons.Windowcatches
locatedontheverticaledgeofthewindowdonothave
lockbuttons.Variouswindowxingshavebeenused
inthecaravan.
Fully adjustable window stays
To open
• Shouldtherebealockingbutton,pressittoworkthewindow
catch.
• Turnallcatches
j
by90°.
• Pressthewindowcatchoutwardswithyourhanduntilitisopen
asfarasyouwouldlike.Thenuseyourotherhandtotighten
theturnscrew
l
untilyoufeeltheresistanceandthewindow
isheldinplace.
To close
• Loosentheturnscrew
l
toallowyoutoclosethewindow.
• Turnallthecatchesbacktotheiroriginalpositionsothatthey
lockbehindthelatchesandpullthewindowintotheseal.
Shouldtherebelockbuttons,theymustclickbacktotheir
originalposition.
Windowsmustbeclosefullywhiledriving.Neverusede-
icingsprayoranicescraperforthewindowsinthecaravan.
Highhumiditymaycausealightmisttoformwithin
thewindowpanes.Thiswilldisappearbyitselfwhen
theweatherisdrier.
1
2
Closed Vent position
Apartfromtheopenandclosedpositions,thewindow
catchescanalsobelockedinthemiddleslotofofthe
latchestoallowairin,thisistheventposition.
3
Closed window
