14. Technical Data
14.4 Tyres and Rims
Standard
version
Metal wheel rims for
the standard version
Light alloy rims for
the standard version
Metal wheel rim: tightening torque 10 Nm
Light alloy rim: tightening torque 120 Nm
Tyre bolts: retainer for all 13" + 14" metal wheel rims and all light alloy rims (incl. 15"): cone washer
retainer for all 15" metal wheel rims: SPHERICAL WHEEL BOLT Tyre bolts M12 x 1,5 x 30 10,9
Model Tech-
nical
name
ONTOUR De Luxe
Edition
IC Line De Luxe Excellent Prestige Premium
Technically
permissi-
ble total
mass.
[kg]
Axle
load
[kg]
Metal
wheel
rim
Tyre size Air
pres-
sure
(bar)
Light
alloy
rim,
size
Light
alloy
rim,
marking
Light
alloy
rim,
colour
Tyre size Air
pres-
sure
(bar)
390 SF P28B • 1200 1200 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
400 SFe S15K • 1300 1300 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
440 SF F28A • 1300 1300 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
455 UF N22K • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
460 LU J52? • • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
460 UFe C43? • • • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
460 DL R68B • 1300 1300 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
460 SFf H48L • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
470 UL V24B • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
470 KMF K33B • 1350 1350 5½ x 14 195/70 R 14 XL LI 96 3,2 6 x 14 OJ14/5 silver 195/70 R 14 C LI 101 4,5
490 KMF A33? • • 1400 1400 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• •
495 UFe F43L • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
•
495 UL L24? • • • • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• • • •
495 UL L24A • 1800 1800 Light alloy rims are part of the standard equipment 6 x 15 OJ15/5 silver 195/70 R 15 C LI 104 4,5
495 UL L24H • 1700 1700 Light alloy rims are part of the standard equipment 6 x 15 OJ 15/5 black 195/70 R 15 C LI 104 4,5
495 WFB D64? • • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• •
540 UL M24? • • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• •
540 FU E37? • • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• •
540 UFf K40L • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
•
540 WLU J49L • 1500 1500 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
•
540 KMFe P33? • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
515 UHK G67K • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
515 UHL G69K • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
545 KMF R33? • • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
• •
545 KMF R33A • 2000 2000 Light alloy rims are part of the standard equipment 6 x 15 OJ15/5 silver 225/70 R 15 C LI 112 4,5
560 LU B52? • • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
560 UL B24H • 1800 1800 Light alloy rims are part of the standard equipment 6 x 14 OJ 14/5 black 195 R 14 C LI 106 4,5
560 KMFe C33? • • • 1700 1700 5½ x 15 195/70 R 15 C LI 104 4,5 6 x 15 OJ15/5 silver 195/70 R 15 C LI 104 4,5
•
• •
560 KMFe C33A • 1800 1800 70 6 x 15 OJ15/5 silver 195/70 R 15 C LI 104 4,5
560 WFU Y50? • • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
560 WLU H49M • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
560 CFe T58L • 1600 1600 5½ x 14 185 R 14 C LI 102 4,5 6 x 14 OJ14/5 silver 185 R 14 C LI 102 4,5
560 CFe T58H • 1800 1800 Light alloy rims are part of the standard equipment 6 x 14 OJ 14/5 black 195 R 14 C LI 106 4,5
