6. Interior structure
49
Hanging table
To lower
•
 Raisethefrontendofthetabletopbyapprox.30°.
• Pulldownthelowerpartofthetableleg
j
,folditoverby90°
andlayitonitsend.
• Foldoutthesupportinglegs
k
by90°.
•
Pullthetabletopoutoftheupperwallbrackets
l
.
• Raisethefrontendofthetabletopconsiderablyandhookit
diagonallyfromaboveintothelowerwallbrackets
m
.
• Placethesupportinglegsatthefrontedgeofthetabletopon
theoor.
3
2
1
4
Hanging table
Supporting legs
Lowered hanging table
6.4 How to convert seating areas into beds
Preparing to convert the bed
• Lowerthetable(see Chapter 6.3 Tables).
• Ifnecessary,foldoutthebedexpansionintheseatingarea
(model-specic).
Theseatgroupscanbeconvertedintocomfortablebeds.
Converting the seating area to a bed
Converting the seating area
Notes on arranging the cushions:
- Howtoarrangethecushionsdependsonthecaravanmodel.
- Insomecaravanmodels,oneormoreadditionalcushionsare
requiredtoconvertthebed.Theseareincludedseparatelyin
thecaravan.
- Inmainseatingarea,therearseatcushions
j
remaininplace.
- Dependingonthe model,itmay benecessary toremovethe
sideback
k
andseatcushions
l
.Todothis,pushtheseat
cushions
l
towardsthemiddleandplacethebackcushions
k
horizontallyalongthesides.Anyopenspacethatcanstillbe
seen/feltshouldbelledwithoneormoreadditionalcushions.
.
1
1 1
2
2
3 3
Neitherthemetalelevatingtablelegnorthesingle-post
elevating table leg are fastened to the oor. Before
driving,lowerthetableand,dependingonthemodel,
secureitwithoneortwopushbuttonseithertotheseat
baseortothefront/rearwall.
Securing the table
