8-9
HRN216 FUEL SYSTEM
15. Reinstall the main nozzle and main jet, making sure the
nozzle long end extends into the venturi.
16. Install the float valve, float, and float chamber.
• Make sure the float valve is properly attached to the float.
• Ensure the float chamber is installed correctly, making a
good seal with the gasket.
17. Reinstall the carburetor on the engine, turn the fuel valve on,
and check for fuel leaks.
18. Start the engine and allow it to warm up for several minutes.
Check the maximum no load engine speed.
