9-3
HRN216 IGNITION COIL/FLYWHEEL
VLA TYPE
Remove the fan cover (P. 7 -3 ).
Disconnect the stop switch cord and charge coil connectors.
After installation, adjust the ignition coil air gap (P. 9 -6
).
IGNITION COIL
SPARK PLUG CAP
STOP SWITCH CORD CONNECTOR
6 x 23 mm BOLT (2)
CHARGE COIL CONNECTOR
