Commissioning
P
age 22
3.3.7 Display control and password protection
Item Name Description
W2= Protection level 2 Enter protection level 2 (default password: ENRAF2)
DF= Display format One character. Selects the data which will be shown on the XPU
display (refer to Appendix D for a detailed overview).
A : level and temperature
B : level
C : average gas temperature
D : average product temperature
E : HIMS density
F : pressure P1
H : pressure P3
I : servo density
J : analog level output
K : water level from external HART probe (only with XPU-2)
DG= Tenth millimetre selection One character. Only active when level dimension is metres.
Y : for tenth millimetre indication
N : for millimetre indication
DJ= Zero format One character which selects how the number zero is displayed:
0 : as an “0” with “slash”
O : as a capital letter “O”
DY= Display selection One character. Only applicable with XPU-2.
Y : display connected
N : no display connected
Note:
W
hen the display is present, but item DY is set to N, no data will be
shown on the display.
W1= Password 1 Six characters, default password is: ENRAF1. You can define your
own level 1 password by entering six characters.
Password 1 is read protected if strap J(A)1 on the XPU(-2) board is in
position ‘1’.
W2= Password 2 Six characters, default password is: ENRAF2. You can define your
own level 2 password by entering six characters.
Password 2 is read protected if strap J(A)2 on the XPU(-2) board is in
position ‘1’.
WM= Weights & Measures Four characters; either ‘A’ (feature W&M approved) or ‘N’ (feature not
protection W&M approved). If the N is selected for a feature, the level dimension
and level type on the display will be replaced by hashes: ‘### ###’.
Position Feature
1 Product level (I1)
2 Interface 1 / interface 2 (I2)
3 Water level (I3, or external water probe)
4 Dip mode on interface 1
EX Exit Exit protection level.
