Appendix B Additional information on displacers
Displacer type Part number
Displacer area (DA)
[cm
2
]
Displacer volume (DV)
[cm
3
]
Displacer weight (DW)
[g]
Carbon filled PTFE
ø 25 mm
ø 45 mm
ø 90 mm
ø 110 mm
S0815360
S0815343
S0815344
S0815345
+.10000000E+02
+.16000000E+02
+.64000000E+02
+.95000000E+02
+.10500000E+03
+.10500000E+03
+.10500000E+03
+.10500000E+03
+.22300000E+03
+.22300000E+03
+.22300000E+03
+.22300000E+03
Stainless steel
ø 90 mm
ø 110 mm
ø 140 mm
0815.171
0815.173
0815.175
+.64000000E+02
+.95000000E+02
+.15400000E+03
+.60000000E+02
+.10000000E+03
+.17500000E+03
+.22300000E+03
+.22300000E+03
+.22300000E+03
Density displacer
(stainless steel)
ø 90 mm
ø 43 mm
S0815350
S0815355
+.64000000E+02
+.16000000E+02
approximately 200;
exact value is
engraved on displacer
approximately 265;
exact value is
engraved on displacer
