BENDIX/KING RDR 2000
Rev 7, July/2002 00643I05.TDC Page 1-3
Within 15 seconds after the button is released, the track cursor and the numerics will disappear
from the display. The track cursor is also used to select the location of the vertical slice to be
viewed in the Vertical Profile mode.
IN 182A P/N 066-3084-00 through -03 will not support the Vertical Profile feature of the RDR 2000.
1.2.3 AA2010V/H AND AA2012V/H ANTENNAS
These are aluminum alloy, slotted, flat plate antennas. The AA2010V and AA2012V are vertically
polarized. The AA2010H and AA2012H are horizontally polarized. The AA2010V/H are 10" di-
ameter antennas and the AA2012V/H are 12" diameter antennas.
1.2.4 CM 2000 CONFIGURATION MODULE
The Configuration Module stores the configuration and calibration data for the RDR 2000 system.
The module can be programmed with configuration data in the system if installed in conjunction
with EFIS that has software level 09 or higher.
In all other installations, the Configuration Module must be programmed with configuration data
outside the system using the KPA 900 Configuration Module Programmer Kit (P/N 050-03311-
0000) along with a personal computer.
All calibration data is programmed with the module in the system, regardless of the type of instal-
lation.
1.3 TECHNICAL CHARACTERISTICS
1.3.1 ARINC 429 INFORMATION
The following are serial digital input labels to the ART 2000:
The following are serial digital outputs from the ART 2000:
LABEL INFORMATION CONTAINED IN LABEL FORMAT SPEED
270 Radar Control Word #1 DSC Low Speed
271 Radar Control Word #2 DSC Low Speed
273 Vertical Profile Control Word DSC Low Speed
275 RDR Control Word #3 DSC Low Speed
276 Radar Control Panel Control Word DSC Low Speed
324 Pitch Angle BNR High Speed
325 Roll Angle BNR High Speed
177 Time/Temp Recorder Data Request Low Speed
LABEL INFORMATION CONTAINED IN LABEL FORMAT SPEED
177 Time/Temperature Recorder Data Low Speed
