BENDIX/KING RDR 2000
Rev 7, July/2002 00643I05.TDC Page 2-23
TABLE 2-2 CALIBRATION PARAMETERS IN AZIMUTH COUNT FIELD
FIGURE 2-10 GAIN KNOB CALIBRATION FUNCTION
DIGIT IN AZIMUTH COUNT FIELD CALIBRATION PARAMETER
00 NONE
01 400 HZ REFERENCE
02 PITCH GAIN
03 ROLL GAIN
04 PITCH OFFSET
05 ROLL OFFSET
06 AHRS ARINC 429 PITCH OFFSET
07 AHRS ARINC 429 ROLL OFFSET
08 SAVE CONFIGURATION
