BENDIX/KING RDR 2000
Page 1-4 00643I05.TDC Rev 7, July/2002
1.3.2 UNIT INFORMATION
ART 2000 ANTENNA/RECEIVER/TRANSMITTERS
TSO COMPLIANCE: See Appendix E
TEMPERATURE RANGE:
-55
°
C to +70
°
C with antenna
ALTITUDE: 55,000 ft. unpressurized
WEIGHT: 9.9 lbs. (4.49 kg.)
OVERALL DIMENSIONS:
Base: 10.00 in. (25.40 cm)
INPUT POWER REQUIREMENTS: 2.0 amps. at 28 Vdc.
2.5 amps. at 17 Vdc.
RADAR TRANSMITTER:
RF Power Output: 2.5 kW to 6.0 kW.
3.3 kW nominal.
Frequency (X-band):
9375 MHz
± 30 MHz
Pulse Repetition Freq:
106.5 Hz
± 5 Hz
Pulse Width: 4 µsec. nominal (GMAP and WX modes)
Weather Avoidance Range Capability: 279 NM max. with 10" antenna
305 NM max. with 12" antenna
RADAR RECEIVER:
Sensitivity: -110 dBm typical.
STC: Effective 0 to 30 NM with 10" antenna
Effective 0 to 35 NM with 12" antenna
Weather Compensation (Wx mode only): 0 to 240 NM
Extended STC: Effective 40 to 240 NM.
Manual Gain Control: Greater than 16 dB at normal room tempera-
ture
Gain Reduction Greater than 14 dB from -55° to +70°C
