Hardware Troubleshooting
Part No.: 4417594_Rev11 Troubleshooting & Maintenance Guide
CIU 888 3 - 3
d) Check the power regulators for any signs of damage. Replace a
defective power regulator or have it replaced.
3.2 Boot failure
Problem
After switching the CIU 888 on, the error message ‘Boot Failed’ appears
on the CIU 888 display (see FIGURE 3-4).
FIGURE 3-4 CIU 888: ‘Boot Failed’ error message
Solution
Perform the following steps:
1. Perform a power cycle by switching the CIU 888 off and back on
using the on/off switch at the back of the CIU 888.
2. Connect a VGA monitor to the VGA port at the back the CIU 888 to
view the BIOS messages (memory module error, corrupted BIOS
settings, et cetera.).
3. Install a new CompactFlash with a working image or have it installed.
NOTE: Apart from replacing the CompactFlash Card, no field repairs are currently
possible.
3.3 FPGA load failure
Problem
After switching the CIU 888 on, the error message ‘FPGA Load Failed’
appears on the CIU 888 display.
Solution
Perform the following steps:
1. Perform a power cycle by switching the CIU 888 off and back on
using the on/off switch at the back of the CIU 888.
