53
Item Item Name & Description
587 Start Time
A user selected time of day when selected items are re-zeroed and the next day’s
calculations begin. Generally the "Start Time" is set to midnight to coincide with the
calendar day, but other top of the hour times may be entered.
Default: 00 00 00
588 Instrument Baud Rate
Codes (0-8) are to select the instrument’s baud rate for all local serial
connection. If
Auto baud is selected the instrument will connect to the computer at the baud rate at
which the software is set. If any other selection is made the computer baud rate must
match that of the instrument in order to communicate.
Code Value Code Value
0 9600 5 Not Used
1 4800 6 19200
2 2400 7 38400
3 1200 8 Auto Baud - Default
4 Not Used
Audit Report Items-Default
The ten user-selectable recorder items that can be stored in memory and then used to
create historical data based on the selected Audit Trail items. Any of the instrument's
items can be selected, but generally should be restricted to items whose value can be
graphed, such as pressure or temperature, etc. Any report position can be left blank
(unused) by inserting the number "255" instead of an i
tem code number.
Pressure only default Audit Trail
589 Report Item 2 500, P1 Pressure
590 Report Item 2 651, P1 Interval Low Pressure
591 Report Item 3 650, P1 Interval High Pressure
592 Report Item 4 649, P1 Interval Avg. Pressure
593 Report Item 5 672, P1 Current Day Low Press.
594 Report Item 6 681, P1 Current Day Low Time
595 Report Item 7 671, P1 Current Day Hi
gh Press
596 Report Item 8 679, P1 Current Day Hi time
597 Report Item 9 503, Case Temperature
598 Report Item 10 521, Battery Voltage Reading
599 Time Trigger Enable
When enabled, item 585 log interval will cause an Audit Trail record to be placed in
memory and is indicated by the log trigger: Time.
Code Value
0 Inactive
Default: 1 Active
