Honeywell HW7000EH Service Manual

BOLT AND FASTENER TORQUE INFORMATION
3-2 www.honeywellgenerators.com Honeywell Portable Electrical Generator Service Manual
3.2 BOLT AND FASTENER TORQUE INFORMATION
Component-Specific Fastener Fastener Size
Torque Values
N•m lb. ft.
Alternator End Cover Bolts M5 x 12 4 3
Alternator Housing Bolts M10 x 1.25 x 80 48 35
Axle Bracket Bolts M8 x 16 25 18
Brush Assembly Bolt M5 x 16 2 1.5
Carbon Canister Bracket Bolts M6 x 1.0 x 10 2 1.5
Control Panel Bolts M6 x 1.0 x 15 4 3
Exhaust Pipe Nuts M8 x 1.25 24 17
Fuel Tank Mounting Bolts M6 x 1.0 10 7
Fuel Shut-off Valve Hex Fitting M10 x 1.25 24 17
Muffler to Engine Bolts M8 x 1.25 29 22
Spark Arrestor Bolts M6 x 0.8 x 10 2 1.5
Support Leg to Frame Bolts M8 x 16 25 18
Support Leg to Rubber Stopper Bolts M8 x 25 25 18
Wheel Handle Pivot Bracket Bolts M6 x 40 10 7
Engine Torque Values See Honda Owner’s Manual
TABLE 3-4. Torque Values

Honeywell HW7000EH Specifications

General

Brand	Honeywell
Model	HW7000EH
Category	Portable Generator
Language	English
