CONTROL PANEL
9-8 www.honeywellgenerators.com Honeywell Portable Electrical Generator Service Manual
9.6 CONTROL PANEL
A—CONTROL PANEL ASSEMBLY
(FRONT)
4 N•m (3 lb. ft.)
B—CONTROL PANEL ASSEMBLY
(BACK)
C—MAIN CONTROL PANEL
(FRONT)
• 125VAC 20 Amp Duplex
(NEMA 5-20R)
• 125/250VAC 30 Amp Twist-Lock
(NEMA L14-30R)
• Master Circuit Breaker (Magnetic)
• Circuit Breaker (Thermal)
• Hour Meter
D—MAIN CONTROL PANEL (BACK)
E—SWITCH PLATE (FRONT)
F—START / STOP / RUN SWITCH
G—SWITCH PLATE (BACK)
START
ENGINE
STOP
RUN
B
D
A
E
C
F
G
