28
Mounting and Connection Instructions IB2 16 I/O Expander
Honeywell Security Group
Novar GmbH
Johannes-Mauthe-Straße 14
D-72458 Albstadt
www.honeywell.com/security/de
2016-01-19
© 2016 Novar GmbH
P00185-10-002-03
10. Technical Data
Rated operating voltage 12 V DC
Operating voltage range 9.5 V DC to 15 V DC
Current consumption at UB = 12 V DC:
- No-load current operating mode BUS-2 20 mA
- No-load current operating mode IB2 55 mA
- Per closed input (12k1) 0.6 mA
- Per closed input (1K) 3.0 mA
- High-active output max. 50 mA
- Low-active output max. 50 mA
- Input as output Low-aktiv max. 50 mA
U_EXT (input voltage for high active outputs) 5 V DC to 30 V DC
Environmental class as per VdS II
Environmental class as per EN 50131-1 Class II
Operating temperature range -10 °C to +45 °C
Storage temperature range -25 °C to +70 °C
Relative humidity max. 75% non-condensing
Weight 180 g
Dimensions PCB (B x H x T) 112 x 158 x 20 mm
Module as per EN 50131-3, Security Grade 3, Environmental Class II
As per SES-EMA-RL-T2:2010-08
Conformity
