16 NFS2-3030 Operations Manual — P/N 52546:A 11/29/2005
General Information The Main Menu
Pressing an ACCEPT soft key will save information entered on the screen. It may also return to the
previous screen and/or perform other functions as described in the soft key section for each screen.
When the panel can not read a specified point (that is, if the point entered on the screen for
processing does not exist in the panel’s programming) it will display an error screen for several
seconds, then return to the screen where the address was entered. The user must check his input and
investigate the state of the point.
1.8 The Main Menu
The Main Menu screen is the means by which the programmer can access displays, history
information, printing and programming menus. This screen is accessible from the System Normal
Screen (Refer to Figure 1.2), and from most other screens by pressing the BACK soft key until it
displays.
Figure 1.5 Main Menu Screen
Soft Keys
Pressing the soft keys brings the user to the screens described below.
1.8.1 Event Counts Display
Pressing the soft key to the left of the Event Counts Display message on the Main Menu
brings up the Event Counts screen. This screen will automatically display if an off-normal event
requiring acknowledgement occurs, unless the panel is in programming mode. Fire alarm events
will display even in programming mode.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A WED AUG 24, 2005
EVENT COUNTS DISPLAY READ STATUS
PROGRAM/ALTER STATUS
MULTIPLE EVENT LIST PRINTER FUNCTIONS
HISTORY DISPLAY BACK
