NFS2-3030 Operations Manual — P/N 52546:A 11/29/2005 53
Point Range Select for All Events in Range Viewing and Printing History Information
ACCEPT: - When entries are made, press this soft key to proceed to the All Events in Interval
Screen.
All Events in Interval Screen
This screen is the same as the Event History screen, except for its title. Refer to Figure 4.1 on page 51.
4.3 Point Range Select for All Events in Range
Pressing the Point Range soft key on the Local History Select screen displays the Point Range
Select screen. This screen allows for selection of a beginning and an end point that defines the
range of events to be viewed and/or printed.
Range is selected in the following order:
1. Loop 1 Detectors
2. Loop 2 Detectors, etc.…
3. Loop 10 Detectors
4. Loop 1 Modules
5. Loop 2 Modules, etc. …
This FACP can have up to 10 loops, which would all follow the above order for range selection.
20. Loop 10 Modules
The range selected below includes all supervisory event types for every point: the selection begins
with the first detector on loop one and ends with the last module on loop 10.
Figure 4.3 Point Range Select Screen
Display
See description in Section 4.1, “Events History”, on page 51 for lines 1-5.
Soft Keys
START POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter a start
point for event viewing.
END POINT: - Press this key to scroll through the list of various device types: the format will
change for each device. Stop at the desired format/device type, then use the keypad to enter an end
point for event viewing.
LAKEVIEW GENERAL HOSPITAL
SYSTEM NORMAL
11:58:45A WED AUG 24, 2005
POINT RANGE SELECT
START POINT:
L01D001 (DETECTOR)
END POINT:
L10M159 (MODULE)
EVENT TYPE: SUPERVISORY ACCEPT
BACK
To Next Page
