Honeywell PC42T User Manual

Chapter 2 — Connect the Printer
PC42t Desktop Printer User Guide 23
How to Connect the Printer to Your PC
You can connect the printer to your PC using one of these cables:
• USB cable
• Serial cable
Connect the Printer with a USB Cable
The printer supports USB connections to a desktop PC. You do not need
to set any parameters for USB communications.
1 Download and install InterDriver on your PC.
2 Connect one end of the USB cable to the USB device port on the
back of the printer and when prompted during the InterDriver
installation, connect the other end to your PC.
Connect the Printer with a Serial Cable
If you have the optional factory-installed serial port on your printer, you
can connect the printer to the serial port on a PC.
1 Connect one end of the serial cable to the connector on the back of
the printer and connect the other end to your PC.
2 Configure the serial port settings with the printer web page or with
PrintSet.
Note: You must install InterDriver to use a USB connection to a
Windows PC. For more information, see the PrinterCompanion CD that
came with your printer or the InterDriver installation instructions above.

Honeywell PC42T Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104.1 mm
Certification	UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, QR Code
Display	LED
Product color	Black
Ethernet LAN	Yes
Optional connectivity	Ethernet, Parallel, Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ribbon width	109.2 mm
Core diameter	25.4 mm
Ribbon length	300 m
Maximum label width	110 mm
Maximum media length	9.6 mm
Maximum roll diameter	127 mm
Supported paper width	25.4 - 110 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	297 mm
Width	226 mm
Height	177 mm
Weight	2500 g
