Chapter 3 — Troubleshoot and Maintain the Printer
38 PC42t Desktop Printer User Guide
Clean the Platen Roller
Follow this procedure to remove, clean, and replace the platen roller as
part of standard maintenance for the printer. You should check the platen
roller for debris each time you load media and clean it if dirty.
1 Turn the printer off and disconnect the power cord.
2 Press in on the cover latches on both sides of the printer and open
the cover.
3 Press in on the top of both locking tabs to open the print and ribbon
mechanism.
4 Remove the installed media (and ribbon).
5 Pry up on the end of the platen roller near the gear.
Caution: Never use hard or sharp tools to peel away stuck labels or
other material. The platen roller is delicate and can easily be
damaged.

Honeywell PC42T Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104.1 mm
Certification	UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, QR Code
Display	LED
Product color	Black
Ethernet LAN	Yes
Optional connectivity	Ethernet, Parallel, Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ribbon width	109.2 mm
Core diameter	25.4 mm
Ribbon length	300 m
Maximum label width	110 mm
Maximum media length	9.6 mm
Maximum roll diameter	127 mm
Supported paper width	25.4 - 110 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	297 mm
Width	226 mm
Height	177 mm
Weight	2500 g
