66 PX4ie and PX6ie High Performance Printer User Guide
Import a Configuration File from a USB Storage Device
You installed a saved .xml configuration file to a USB storage device to your printer.
Note: If there is more than one configuration file on the USB storage device, the printer
imports the first file found alphabetically by file name.
1. Insert the USB storage device in the printer USB host port.
2. From the Main Menu, select Tools > USB Menu > Configuration > Install
Configuration. The printer imports the configuration file:
• An IPL configuration file is copied to /home/user/config/ipl.
• All other configuration files are incorporated into the current configuration.
When the file is successfully imported, a message appears.
3. to close the message, press .
4. From the Main Menu, select Tools > USB Menu > Remove USB.
5. Remove the USB storage device.
Export a Configuration File to a USB Storage Device
You can save an .xml configuration file to a USB storage device and install it on
other printers.
1. Make sure the USB storage device has a single partition and is formatted as
FAT16 or FAT32.
2. Insert the storage device into the printer USB host port.
3. From the Main Menu, select Tools > USB Menu > Configuration > Export
Configuration. A list of the available files appears.
4. Select the file to export and press . When the file is successfully exported,
a message appears.
5. To close the message, press .
6. From the Main Menu, select Tools > USB Menu > Remove USB.
7. Remove the USB storage device.
Connection Programming Commands
Printer running
Fingerprint
RUN “/system/usr/bin/cfg -o xmlimportset -k /home/user/profiles/
myprofile”
Printer running IPL <STX><ESC>.x,/system/usr/bin/cfg -o xmlimportset -k /home/user/
profiles/myprofile<ETX>
Telnet connection over
Port 23
/system/usr/bin/cfg -o xmlimportset -k /home/user/profiles/myprofile

Honeywell PX6ie Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	300 x 300 DPI
Printable dot numbers	11.8 dot
Maximum printing width	167.4 mm
Display	LCD
Control type	Buttons, Touch
Product color	Gray
Display diagonal	2.3 \
Windows operating systems supported	Yes
RS-232 ports	1
Optional connectivity	Parallel, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Core diameter	76 mm
Maximum label width	170 mm
Maximum roll diameter	80 mm
Flash memory	128 MB
Certification	CE (EN55022 Class B), FCC Class B, UL/cUL, C-Tick
Internal memory	256 MB
Image formats supported	PNG, BMP, GIF, PCX
AC input voltage	90 - 265 V
AC input frequency	45/65 Hz
Power consumption (standby)	5 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Supported network protocols	TCP/IP-suite (TCP, UDP, ICMP, IGMP, etc.), LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP. SNMP-MIB II supported (over UDP/IP), private enterprise MIB included. Supports IPv4 and IPv6, NTP

Weight and Dimensions

Depth	482 mm
Width	335 mm
Height	238 mm
Weight	14130 g
