103
MAN0530 Issue 10 - 11/09 Searchline Excel
2104M0506
C.1 SYSTEM UNITS
The following table lists the different types of system units and provides the part numbers for
thevariouscerticationoptions.
All types of Transmitters and Receivers include conduit and glands. Open-Path Transmitters
and Receivers do not include mounting plates and brackets.
APPENDIX C - ACCESSORIES & SPARE PARTS
Instrument
Searchline Excel Short Range 5m – 40m (15ft - 130ft)
Part Number Description
02104-N-4011 Short range system 5m to 40m ATEX complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,1DVC100MMK2digitaljunction
box, 1 junction box Current Source
02104-N-4041 Short range system 5m to 40m ATEX complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,1DVC100MMK2digitaljunction
box, 1 junction box Current Sink
02104-N-5012
Shortrangesystem5mto40mULcompleteTXRandRXRsystem,fullywiredwithexible
conduit, SS316 mounting plates, brackets, DX100M and Junction Box, Current Source
02104-N-5042
Shortrangesystem5mto40mULcompleteTXRandRXRsystem,fullywiredwithexible
conduit, SS316 mounting plates, brackets, DX100M and Junction Box, Current Sink
02104-N-6012 Short range system 5m to 40m CSA complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplates,brackets,DX100MandJunctionBox,Current
Source
02104-N-6042 Short range system 5m to 40m CSA complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplates,brackets,DX100MandJunctionBox,CurrentSink
Searchline Excel Medium Range 40m – 120m (130ft - 390ft)
02104-N-4021 Medium range system 40m to 120m ATEX complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,1DVC100MMK2digitaljunction
box, 1 junction box Current Source
02104-N-4051 Medium range system 40m to 120m ATEX complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,1DVC100MMK2digitaljunction
box, 1 junction box Current Sink
02104-N-5022 Medium range system 40m to 120m UL complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,DX100M,JunctionBox.Current
Source
02104-N-5052 Medium range system 40m to 120m UL complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,DX100M,JunctionBox.CurrentSink
02104-N-6022 Medium range system 40m to 120m CSA complete TXR and RXR system, fully wired with
exibleconduit,SS316mountingplatesandbrackets,DX100M,JunctionBox.Current
Source
