Honeywell Searchline Excel User Manual

12
MAN0530 Issue 10 - 11/09 Searchline Excel
2104M0506
2.4 ADJUSTABLE MOUNTINGS
The adjustable mountings are:
• Purpose-builtforTransmitterandReceiver.
• Robust.
 • Rigidandstable.
 • Madefromstainlesssteel.
 • Fullyadjustableforalignment
Coarse and ne settings in both horizontal and vertical planes.
Adjustment range:
Vertical ±45
o
Horizontal ±90
o
Alignment details are given in Chapter 3.
2. OVERVIEW
Clamp nut
Mounting bracket
adjusting screw (2 off)
Adjustment clamp
lock screw (2 off)
Clamp nut
Pivot block
adjusting screw
Adjustment clamp
lock screw (2 off)
