83
MAN0530 Issue 10 - 11/09 Searchline Excel
2104M0506
A.4 BASIC USER TASKS
Switching On
(1) Press for two seconds.
The unit recalls its previously set operating mode, i.e.
EXCEL, OPTIMA or OPTIMA
PLUS, and displays the following message for approximately three seconds:
Z - SHC1 EXCEL
Interrogator 4V0
The unit then displays the top level of the menu style interface in the following way:
Main
Display
During use the rst line of the display shows the current level in the menu tree.
The second line displays the sub menu title, action to be invoked, or data value to be
checked/changed.
Note: To change the operating mode at switch-on, e.g. from OPTIMA to EXCEL, press the
ESC key whilst the initial message is displayed. This changes the mode and re-displays
the message.
Switching Off
(1) Select the Power Off option from the Main Menu,
Alternatively press the
and ESC buttons simultaneously for a fast power off.
Notes:
1. The unit powers down automatically after ve minutes of non-use.
2. The fast power off facility and auto power off are disabled when a menu option is selected
that modies the interrogator’s conguration.
CAUTION
Onlyusebatteriesspeciedbelow.
Replace the battery only in a Safe Area.
To replace the battery in the Hand-Held Interrogator SHC-1 proceed as follows:
OLDER ATEX VERSIONS CERT. NO. Baseefa03ATEX0073X, IECEx BAS 09.0120
ONLY USE DURACELL MN1604 TYPE 6LR61
(1) Remove the Interrogator from its protective pouch.
(2) Using a 2.5mm allen hexagonal key, loosen the four screws on the rear cover of the
Interrogator.
>
>
APPENDIX A - HANDHELD INTERROGATOR
