6.1 SYSTEM
OPEN-PATH
SHORT RANGE MEDIUM RANGE LONG RANGE
Available Gases All: Methane, Ethane, Propane, Butane, Pentane, Ethylene, Propylene, Butadiene.
Range 0 - 5 LELm 0 - 5 LELm 0 - 5 LELm
Recommended Low 1 LELm Low 1 LELm Low 1 LELm
Alarm Setting High 3 LELm High 3 LELm High 3 LELm
Minimum Alarm 0.5LELm 0.5LELm 0.5LELm
Setting
Path Length 5 - 40m 40 - 120m 120 - 200m
(15 - 130ft) (130 - 390ft) (390 - 650ft)
Speed of T90 less T90 less T90 less
Response than 3seconds than 3seconds than 3seconds
Output signal 4 – 20mA 4 – 20mA 4 – 20mA
Normal operation Normal operation Normal operation
(0 – 5LELm) (0 – 5LELm) (0 – 5LELm)
Operating Temp.  All:-40°Cto+65°C(-40°Fto+150°F)
Humidity All: 0 – 99%RH Non-condensing
Pressure All: 91.5kPa – 105.5kPa (915 – 1055mBar, non-compensated)
Repeatability
±0.4LELm ±0.4LELm ±0.4LELm
Temperature ±0.2LEL.m @ zero ±0.2LEL.m @ zero ±0.2LEL.m @ zero ±10%LEL (%LEL/m) @ zero
Drift (-40°C to+65°C) ±0.5LEL.m @3LEL.m ±0.5LEL.m @3LEL.m ±0.5LEL.m @3LEL.m ±15%LEL (%LEL/m) @ 60%LEL
Warm-up Time All: less than 5 minutes (operational), Less than 1 hour (fully stabilised)
Power Supply All: 18 to 32V
Power Consumption*Turboheatingactivated(below0°C) 
Transmitter 3.5/5* W max 5.5/7.5* W max. 5.5/7.5* W max.
Receiver 8W maximum 8W maximum 8W maximum
Enclosure Material All: 316 Stainless Steel
Weight
Transmitter 3.5kg 7.0kg 7.0kg
Receiver 3.5kg 3.5kg 3.5kg
Vibration All: 2 – 60Hz, maximum peak to peak amplitude 1mm.
Divergence/ ±0.5° ±0.5° ±0.5°
Misalignment (~±35cm (~±105cm (~±175cm
Tolerance
at 40m) at 120m) at 200m)
IP rating All: IP66/67
