HP 34970A User Manual

Multiplexer Module Default Settings
The table below shows the default settings for each measurement
function on the multiplexer modules. When you configure a channel for
a particular function, these are the default settings.
Temperature Measurements
Temperature Units
Integration Time
Display Resolution
Thermocouple Type
Open T/C Detection
Reference Junction Source
RTD Type
RTD Reference Resistance
Thermistor Type
Channel Delay
Voltage Measurements
Range
Resolution
Integration Time
Input Resistance
AC Low Frequency Filter
Channel Delay
Resistance Measurements
Range
Resolution
Integration Time
Offset Compensation
Channel Delay
Frequency/Period Measurements
Range
Resolution
AC Low Frequency Filter
Channel Delay
Current Measurements
Range
Resolution
Integration Time
AC Low Frequency Filter
Channel Delay
Default Setting
°C
1 PLC
0.1
°C
Type J
Off
Internal
α = 0.00385
R
0
= 100Ω
5 k
Ω
Automatic Delay
Default Setting
Autorange
5
1
⁄
2
digits
1 PLC
10 M
Ω (fixed for all DCV ranges)
20 Hz (medium)
Automatic Delay
Default Setting
Autorange
5
1
⁄
2
digits
1 PLC
Off
Automatic Delay
Default Setting
Autorange
5
1
⁄
2
digits (frequency), 6
1
⁄
2
digits (period)
20 Hz (medium)
Automatic Delay
Default Setting
Autorange
5
1
⁄
2
digits
1 PLC
20 Hz (medium)
Automatic Delay
Chapter 4 Features and Functions
Multiplexer Module Default Settings
162
