HP 34970A User Manual

To Output a DC Voltage
The multifunction module (HP 34907A) has two analog outputs capable
of outputting calibrated voltages between
±12 volts.
1Select a
DAC Output channel.
Select the slot containing the multifunction module and continue
turning the knob until
DAC is displayed (channel 04 or 05).
2 Enter the output voltage editor.
9'$&
3 Set the desired output voltage.
Use the knob and or keys to edit the individual digits.
9'$&
4 Output the voltage from the selected DAC.
The output voltage will be displayed until you press another key or turn
the knob. To manually reset the output voltage to 0 volts, press .
2
Chapter 2 Front-Panel Overview
To Output a DC Voltage
45
