HP 5130 EI Switch Series User Manual

38
Figure 45 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
(3) RPS receptacle
HP 5130-48G-2SFP+-2XGT EI
Figure 46 Front panel
(1) 10/100/1000Base-T autosensing Ethernet port
(2) 10/100/1000Base-T autosensing Ethernet port LED
(3) SFP+ port
(4) Console port
(5) 1/10GBase-T autosensing Ethernet port
(6) System status LED (SYS)
(7) RPS status LED (RPS)
(8) 1/10GBase-T autosensing Ethernet port LED
(9) SFP+ port LED
Figure 47 Rear panel
(1) AC-input power receptacle
(2) RPS receptacle
(3) Grounding screw
1 2
3
1 2 3
7
4 5
6
9
8
1 2
3
