51
10/100/1000Base-T autosensing Ethernet port LED
The H P 513 0 -48G-2SFP+-2 X GT E I , H P 513 0 -48G-PoE+-2SFP+-2XGT (370W) EI, HP
513 0 -24G-SFP-4SFP+ EI, H P 513 0 -48G-4SFP+ EI, H P 513 0 -48G-4SFP+ EI BR, HP
513 0 -48G-PoE+-4SFP+ (370W) EI, and H P 513 0 -48G-PoE+-4SFP+ (370W) EI BR switches provide
a double-color (green and yellow) LED for each 10/100/1000Base-T autosensing Ethernet port to
indicate its operating status.
Table 23 10/100/1000Base-T autosensing Ethernet port double-color LED description
Switch model
Port mode
LED (Mode)
status
Double-color
(green and
yellow) LED
status
Description
H P 513 0 -48G-4SFP+ EI
H P 513 0 -48G-4SFP+ EI
BR
H P 513 0 -24G-SFP-4SFP+
EI
HP
513 0 -48G-2SFP+-2XGT
EI
N/A
Steady green
The port is operating at 1000 Mbps,
and a link is present on the port.
Flashing green
The port is sending or receiving data at
1000 Mbps.
Steady yellow
The port is operating at 10/100 Mbps,
and a link is present on the port.
Flashing yellow
(not 3 Hz)
The port is sending or receiving data at
10/100 Mbps.
Flashing yellow
(3 Hz)
The port has failed POST.
Off No link is present on the port.
HP
513 0 -48G-PoE+-4SFP+
(370W) EI
HP
513 0 -48G-PoE+-4SFP+
(370W) EI BR
HP
513 0 -48G-PoE+-2SFP+-2
XGT (370W) EI
Steady
green (rate
mode)
Steady green
The port is operating at 1000 Mbps,
and a link is present on the port.
Flashing green
The port is sending or receiving data at
1000 Mbps.
Steady yellow
The port is operating at 10/100 Mbps,
and a link is present on the port.
Flashing yellow
(not 3 Hz)
The port is sending or receiving data at
10/100 Mbps.
Flashing yellow
(3 Hz)
The port has failed POST.
Off No link is present on the port.
Flashing
green (PoE
mode)
Steady green The port is supplying PoE correctly.
Flashing green
(3 Hz)
The PD power requirement exceeds
the port PoE capacity.
The port fails to meet the power
requirement of the PD because of
power insufficiency of the switch.
Steady yellow
A non-PD device is attached to the port,
or the port is experiencing a PoE failure.
Flashing yellow
(3 Hz)
The port has failed POST.
