45
Appendix C Ports and LEDs
Ports
Console port
The switch provides a console port.
Table 12 Console port specifications
Item Specification
Connector type
RJ-45
Compliant standard
EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a local or remote (through a pair of
modems) PC running terminal emulation program.
10/100/1000Base-T autosensing Ethernet port
The switch provides 10/100/1000Base-T autosensing Ethernet ports.
Table 13 10/100/1000Base-T autosensing Ethernet port specifications
Item Specification
Connector type
RJ-45
Interface attributes 10/100/1000 Mbps, half/full duplex, MDI/MDI-X autosensing
Max transmission
distance
100 m (328.08 ft)
Transmission medium
Category-5 (or above) twisted pair cable
Compatible standards
• IEEE 802.3i
• 802.3u
• 802.3ab
1/10GBase-T autosensing Ethernet port
The H P 513 0 -24G-2SFP+-2XGT EI, H P 513 0 -48G-2SFP+-2XGT EI, H P 513 0 -24G-PoE+-2SFP+-2XGT
(370W) EI and H P 513 0 -48G-PoE+-2SFP+-2XGT (370W) EI switches provide 1/10GBase-T autosensing
Ethernet ports.
