Status Description
Steady yellow
A transceiver module is installed in the port. The port is operating at 100 Mbps,
and a link is present on the port.
Flashing yellow The port is sending or receiving data at 100 Mbps.
Flashing yellow (3 Hz) The port has failed POST.
Off No transceiver module is installed in the port, or no link is present on the port.
SFP+ port LED
The H P 513 0 -48G-2SFP+-2XGT E I , H P 513 0 -48G-PoE+-2SFP+-2XGT (370W) EI, HP
513 0 -24G-SFP-4SFP+ EI, H P 513 0 -48G-4SFP+ EI, H P 513 0 -48G-4SFP+ EI BR, HP
513 0 -48G-PoE+-4SFP+ (370W) EI, and H P 513 0 -48G-PoE+-4SFP+ (370W) EI BR switches provide
a double-color (green and yellow) LED for each SFP+ port to indicate its operating status.
Table 28 SFP+ port double-color LED description
Status Description
Steady green
A transceiver module is installed in the port. The port is operating at 10 Gbps
and a link is present on the port.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module is installed in the port. The port is operating at 1 Gbps
and a link is present on the port.
Flashing yellow (not 3
Hz)
The port is sending or receiving data at 1 Gbps.
Flashing yellow (3 Hz) The port has failed POST.
Off
•
No transceiver module is installed in the port, or no link is present on the
port.
• The port mode LED is operating in PoE mode (applicable to the PoE switch
models.)
The H P 513 0 -24G-2SFP+-2 X GT E I , H P 513 0 -24G-PoE+-2SFP+-2XGT (370W) EI, HP
513 0 -24G-4SFP+ EI, H P 513 0 -24G-4SFP+ EI BR, H P 513 0 -24G-PoE+-4SFP+ (370W) EI, and HP
513 0 -24G-PoE+-4SFP+ (370W) EI BR switches provide two single-color LEDs for each SFP+ port to
indicate its operating status.
Table 29 Description for the two single-color LEDs for the SFP+ port
LED Status Description
Green LED Steady on
A transceiver module is installed in the port. The port is
operating at 10 Gbps, and a link is present on the port.
