B-4
Switch Ports and Network Cables
Switch Ports and Network
Cables
Copper Cables
10-GbE ER 9/125 μm (core/cladding) diameter, 1550 nm,
low metal content, single mode fiber-optic
cables, complying with the ITU-T G.652 and
ISO/IEC 793-2 Type B1 standards.
SC single-mode cable: 2-30 kilometers
(40 kilometers, on an engineered
fiber optic link that meets standards
in the specification).
10-GbE
LRM
Multimode fiber-optic cable designed for
Gigabit Ethernet: 62.5/125 μm or 50/125 μm
(core/cladding) diameter, graded-index, low
metal content, multimode fiber optic,
complying with the ITU-T G.651 and ISO/IEC
793-2 Type A1b or A1a, respectively. (A mode
conditioning patch cord may be needed in
some multimode fiber installations.)
SC
■ 62.5 μm cable:
• 160/500 MHz/km = 0.5-220
meters
• 200/500 MHz/km = 0.5-220
meters
■ 50 μm cable:
• 400/400 MHz/km = 0.5-100
meters
• 500/500 MHz/km = 0.5-220
meters
• 1500/500 MHz/km = 0.5-
220 meters
OMC CX4
Fiber
12 fiber 50/125 μm (core/cladding) diameter,
multimode Fiber ribbon cable. 12 fiber 62.5/
125 μm (core/cladding) diameter, multimode
Fiber ribbon cable is also supported.
Optical Media
Converter
1-300 meters
Port Type Cable Specifications Connector Type Maximum Length
Port Type Cable Specifications Connector
Type
Supported Length
CX4 Speed 3.125Gbx4
(Cables compliant with the 802.3ak standard)
CX4 0.5-15 meters
